BAE Audio 1028

• Completely hand-wired mic/line preamp

• Uses the same preamp circuit as the 1073

• EQ section modeled after the 1084

• With high quality Carnhill (St. Ives) transformers as in the original from Neve

• Extended EQ settings in the mid and treble range

• Hi- & Low-Cut, Hi-& Low-Shelf and Bell-EQ with wide frequency spectrum

• Shelves and bell filters can be driven against each other and open up a wide range of sound shaping possibilities

• Direct instrument input (Hi-Z DI) via jack plug

• Phantom rotation and EQ bypass

• Switchable input impedance of 1200 or 300Ohm for flexible microphone adjustments


• High-Shelf: ±16dB shelving at 10kHz, 12kHz, 16kHz, 20kHz or 24kHz.
• Low-Shelf: ±16dB shelving at 35Hz, 60Hz, 110Hz & 220Hz
• Center Bell EQ: ±12dB or ±18dB with peak frequency at selectable 160Hz, 270Hz, 360Hz, 510Hz, 700Hz, 1.6kHz, 3.2kHz, 4.8kHz, 7.2kHz, 8.2kHz or 10kHz
• Low-Cut Filter: 18dB per octave, switchable between 45Hz, 70Hz, 160Hz & 360Hz
• High-Cut Filter: 18dB per octave, switchable between 6kHz, 8kHz, 10kHz, 14kHz & 18kHz
• EQ switch: Turns EQ on and off for quick A/B comparison
• Phase switch: 180° phase rotation
• DI switch: increases input impedance to ≈150k ohms for direct instrument pickup
• Weight: 4,54kg

• 19" unit -> 1RU

The BAE Audio 1028 is a high-quality preamp with EQ section, modeled after the legendary Neve 1084 . Equipped with the same preamp circuitry as the Neve 1073 and the same high-cut filter as the 1084 , the 1028 is the ultimate preamp replica for sound fetishists.

Each unit is hand-wired and uses the original Carnhill transformers , which are also responsible for the distinctive sound of the original. For even greater flexibility , the EQ section on the 1028 has also been expanded in the mid and treble bands . The shelf bands now overlap with the mid bark EQ , creating a wide variety of sound shaping possibilities and diverse filter curves.

To meet various studio requirements , phase rotation and 48V phantom power are also switchable. In addition, the front-panel jack line input can be switched to Hi-Z mode to record various instruments directly at the preamp . To accommodate different types of microphones , the input impedance can be switched from 1200 ohms to 300 ohms , which in most cases results in a center-heavy recording sound.

• Производитель:BAE Audio
• Amplifier principle:Transistor
• Number of channels:1x1
• Формат:19"
• Max. Gain in db:80
• Фантомное питание:48V
• Hi-Z входы:1
• Highpass filter:Yes
• Входное сопротивление (Ом):1200
• Additional functions:EQ, Ø, Vari-Z, Hi-Z
• Equivalent Noise (dB):-110
• Transformer balanced:Yes
• Transformer manufacturer:Carnhill
• Адаптер питания:Внешний
• Digital converter:No
